Pin Name

Pin No.

Type

(1)

Main function (3)

Optional multiplexing function

(After reset)

Default

multiplexing

function

Redefining

function

PA2

I/O

PA2

USART2_TX(6)/

ADC12_IN2/

TMR2_CH3(6)

PA3

I/O

PA3

USART2_RX(6)/

ADC12_IN3/

TMR2_CH4(6)

VSS_4

VDD_4

PA4

I/O

PA4

SPI1_NSS(6)/

USART2_CK(6)/

ADC12_IN4

PA5

I/O

PA5

SPI1_SCK(6)/

ADC12_IN5

PA6

I/O

PA6

SPI1_MISO(6)/

ADC12_IN6/

TMR3_CH1(6)

TMR1_BKIN

PA7

I/O

PA7

SPI1_MOSI(6)/

ADC12_IN7/

TMR3_CH2(6)

TMR1_CH1N

PC4

I/O

PC4

ADC12_IN14

PC5

I/O

PC5

ADC12_IN15

PB0

I/O

PB0

ADC12_IN8/

TMR3_CH3(6)

TMR1_CH2N

PB1

I/O

PB1

ADC12_IN9/

TMR3_CH4(6)

TMR1_CH3N

PB2

I/O

PB2/BOOT1

PE7

I/O

PE7

TMR1_ETR

PE8

I/O

PE8

TMR1_CH1N

PE9

I/O

PE9

TMR1_CH1

PE10

I/O

PE10

TMR1_CH2N

PE11

I/O

PE11

TMR1_CH2

PE12

I/O

PE12

TMR1_CH3N

PE13

I/O

PE13

TMR1_CH3

PE14

I/O

PE14

TMR1_CH4

PE15

I/O

PE15

TMR1_BKIN

PB10

I/O

PB10

I2C2_SCL/

USART3_TX(6)

TMR2_CH3

PB11

I/O

PB11

I2C2_SDA/

USART3_RX(6)

TMR2_CH4
