Part numbering

M24C32-W M24C32-R M24C32-F

32/38

Doc ID 4578 Rev 17

Part numbering

For a list of available options (speed, package, etc.) or for further information on any aspect

of this device, please contact your nearest ST sales office.

Table 21.

Ordering information scheme

Example:

M24C32–

W MN 6

P /P

Device type

M24 = I2C serial access EEPROM

Device function

C32– = 32 Kbit (4096 x 8)

Operating voltage

W = VCC = 2.5 V to 5.5 V

R = VCC = 1.8 V to 5.5 V

F = VCC = 1.7 V to 5.5 V

Package

BN = PDIP8(1)

ECOPACK1® (RoHS-compliant).

MN = SO8 (150 mil width)(2)

ECOPACK2® (RoHS-compliant and Halogen-free).

DW = TSSOP8 (169 mil width)(2)

MB = UFDFPN8 (MLP8)(2)

Device grade

6 = Industrial: device tested with standard test flow over –40 to 85 °C

3 = Automotive: device tested with high reliability certified flow(3) over –40 to 125°C.

ST strongly recommends the use of the Automotive Grade devices for use in an automotive environment.

The high reliability certified flow (HRCF) is described in the quality note QNEE9801. Please ask your

nearest ST sales office for a copy.

5 = Consumer: device tested with standard test flow over –20 to 85°C

Option

blank = standard packing

T = Tape and reel packing

Plating technology

P or G = ECOPACK® (RoHS compliant)

Process(4)

Used only for device grade 3 and WLCSP packages.

P = F6DP26% Chartered

A = F8L Rousset (only for the WLCSP package)
