M24C32-W M24C32-R M24C32-F

Signal description

Doc ID 4578 Rev 17

9/38

2.5

VSS ground

VSS is the reference for the VCC supply voltage.

2.6

Supply voltage (VCC)

2.6.1

Operating supply voltage VCC

Prior to selecting the memory and issuing instructions to it, a valid and stable VCC voltage

within the specified [VCC(min), VCC(max)] range must be applied (see Table 7, Table 8 and

Table 9). In order to secure a stable DC supply voltage, it is recommended to decouple the

VCC line with a suitable capacitor (usually of the order of 10 nF to 100 nF) close to the

VCC/VSS package pins.

This voltage must remain stable and valid until the end of the transmission of the instruction

and, for a Write instruction, until the completion of the internal write cycle (tW).

2.6.2

Power-up conditions

The VCC voltage has to rise continuously from 0 V up to the minimum VCC operating voltage

defined in Table 7, Table 8 and Table 9. The rise time must not vary faster than 1 V/µs.

2.6.3

Device reset

In order to prevent inadvertent Write operations during power-up, a power on reset (POR)

circuit is included. At power-up (continuous rise of VCC), the device does not respond to any

instruction until VCC has reached the power on reset threshold voltage (this threshold is

lower than the minimum VCC operating voltage defined in Table 8 and Table 9). Until VCC

passes over the POR threshold, the device is reset and in Standby Power mode.

In a similar way, during power-down (continuous decay of VCC), as soon as VCC drops below

the POR threshold voltage, the device is reset and stops responding to any instruction sent

to it.

2.6.4

Power-down conditions

During power-down (continuous decay of VCC), the device must be in Standby Power mode

(mode reached after decoding a Stop condition, assuming that there is no internal Write

cycle in progress).
