R5F10CMDCLFB датащи(PDF) 41 Page - Renesas Technology Corp |
|
|
|||||||||||||||||||||||||||||
R5F10CMDCLFB датащи(HTML) 41 Page - Renesas Technology Corp |
|
|
41 / 139 page  RL78/D1A 2. PIN FUNCTIONS R01DS0463EJ0120 Rev. 1.20 Page 41 of 135 Mar 31, 2026 2.1.6 Pins for each product (pins other than port pins) (1/6) Function Name I/O Function 48-pin 64-pin 80-pin 100-pin 128-pin R5F10CGx/ R5F10DGx R5F10CLx/ R5F10DLx R5F10CMx/ R5F10DMx R5F10TPx/ R5F10DPx R5F10DSx ADTRG Input A/D conversion start trigger external input 31 43 55 65 53 ANI0/AVREFP A/D converter analog input 4 4 8 10 113 ANI1/AVREFM 3 3 7 9 112 ANI2 2 2 6 8 111 ANI3 1 1 5 7 110 ANI4 − − 4 6 109 ANI5 − − 3 5 108 ANI6 − − 2 4 107 ANI7 48 64 1 3 106 ANI8 − − − 2 105 ANI9 − − − − 104 ANI10 − − − − 103 COM0 Output LCD common output 0 36 48 60 70 58 COM1 LCD common output 1 35 47 59 69 57 COM2 LCD common output 2 34 46 58 68 56 COM3 LCD common output 3 33 45 57 67 55 SEG0 Output LCD segment output 0 32 44 56 66 54 SEG1 LCD segment output 1 31 43 55 65 53 SEG2 LCD segment output 2 30 42 54 64 52 SEG3 LCD segment output 3 29 41 53 63 51 SEG4 LCD segment output 4 28 40 52 62 50 SEG5 LCD segment output 5 27 39 51 61 49 SEG6 LCD segment output 6 26 38 50 60 48 SEG7 LCD segment output 7 25 37 49 59 47, 95 SEG8 LCD segment output 8 − 36 48 58 46 SEG9 LCD segment output 9 24 35 47 57 45 SEG10 LCD segment output 10 − − 46 56 44 SEG11 LCD segment output 11 − − 45 55 43 SEG12 LCD segment output 12 − − 44 54 42 SEG13 LCD segment output 13 − − 43 53 41 SEG14 LCD segment output 14 23 34 42 52 40, 94 SEG15 LCD segment output 15 22 33 41 51 39, 93 SEG16 LCD segment output 16 − 32 40 50 35 SEG17 LCD segment output 17 − 31 39 49 34 SEG18 LCD segment output 18 − 30 38 48 33 SEG19 LCD segment output 19 − 29 37 47 32 SEG20 LCD segment output 20 − − 36 46 31 SEG21 LCD segment output 21 − 28 35 45 30 SEG22 LCD segment output 22 − − 34 44 29 SEG23 LCD segment output 23 − 27 33 43 28, 38 SEG24 LCD segment output 24 21 26 32 42 27, 37 SEG25 LCD segment output 25 20 25 31 41 26, 36 SEG26 LCD segment output 26 19 24 30 40 25, 19 |
|
