11
Application board
The application board (STEVAL-L6983IV1) schematic is shown in the figure below.
Figure 50. Schematic of the application board (unregulated isolated output)
The additional input filter (in the dotted box in Figure 50, on the bottom side of the board) limits the conducted
emission on the power supply. In case the filter is not necessary or should be bypassed for any test, two 0 Ω
resistors should be placed at Rf1 and Rf2.
The isolated output supplied by the board is unregulated. Nevertheless, a post-regulation circuit (see schematic in
Figure 51) is provided on the bottom side (components not mounted). The values and the components indicated
in the BOM below (Table 9 ) are assumed for a dual voltage 18 V / - 5 V.
Figure 51. Proposed circuitry for post-regulation (not mounted, bottom side) for dual voltage (18 V / - 5 V)
If a different dual isolated voltage is necessary (for example, 15 V / - 6 V), the replacement of two components is
enough to adapt the board: the Zener diode DZ2 (with a diode providing the most suitable Zener voltage) and the
resistor divider (one of the two resistors) R1-R2, in accordance with the equation:
VISO+=1.2V∙R1+R2R2+VDZ1
(48)
L6983I
Application board
DS14040 - Rev 1
page 44/56
