Pin Diode Switch Element

Rev. V1

2

2

M/A-COM Technology Solutions Inc. (MACOM) and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice.

Visit www.macom.com for additional data sheets and product information.

For further information and support please visit:

https://www.macom.com/support

2

MEST2G-080-25

Parameter

Absolute Maximum

500 V

200 mA

10°C/W

-40°C to +175°C

-55°C to +150°C

+260°C per

JEDEC STD-J-20C

1. Exceeding any one or combination of these limits may cause

permanent damage to this device.

2. MACOM does not recommend sustained operation near these

survivability limits.

Handling Procedures

Please observe the following precautions to avoid

damage:

Static Sensitivity

These

electronic

devices

are

sensitive

to

electrostatic discharge (ESD) and can be damaged

by static electricity. Proper ESD control techniques

should be used when handling these Class 0 (HBM)

devices.

Insertion Loss

Isolation

Input Return Loss

Output Return Loss
