1.0

ELECTRICAL CHARACTERISTICS

Absolute Maximum Ratings †

ESD Protection (HBM) ...............................................................................................................................................2 kV

† Notice: Stresses above those listed under “Absolute Maximum Ratings” may cause permanent damage to the device.

This is a stress rating only and functional operation of the device at those or any other conditions above those indicated

in the operational sections of this specification is not intended. Exposure to maximum rating conditions for extended

periods may affect device reliability.

DC ELECTRICAL CHARACTERISTICS

Parameters

Symbol

Min.

Typ.

Max.

Units

Conditions

2.215

2.320

2.420

V

At –40°C

2.275

2.350

2.420

At +25°C

2.275

2.350

2.420

At +85°C

1.470

1.610

1.745

V

At –40°C

1.490

1.585

1.680

At +25°C

1.490

1.585

1.680

At +85°C

Input High Voltage

2.075

—

2.420

V

At –40°C

2.135

—

2.420

At +25°C

2.135

—

2.420

At +85°C

Input Low Voltage

1.470

—

1.890

V

At –40°C

1.490

—

1.825

At +25°C

1.490

—

1.825

At +85°C

Output Voltage Reference,

(Note 2)

1.86

—

1.98

V

At –40°C

1.92

—

2.04

At +25°C

1.92

—

2.04

At +85°C

Input High Voltage Common

Mode Range, (Note 3, Note 4)

1.2

—

3.3

V

At –40°C

1.2

—

3.3

At +25°C

1.2

—

3.3

At +85°C

Input High Current, (Note 5)IIH

——

75

µA

At –40°C

——

75

At +25°C

——

75

At +85°C

Input Low Current, (Note 5)IIL

–75

—

—

µA

At –40°C

–75

—

—

At +25°C

–75

—

—

At +85°C

2: Single-ended input operation is limited to VCC ≥ 3V in LVPECL mode.

5: CLK-IN0, CLK-IN1; CLK-IN0B, CLK-IN1B.
