20 / 29 page  MicroSmart Series 30 Programmable Logic Controllers Communication Adapter/Module Part Number FC4A-PC1 FC4A-HPC1 FC4A-PC2 FC4A-HPC2 FC4A-PC3 FC4A-HPC3 Standards EIA RS232C EIA RS485 EIA RS485 Maximum Baud Rate FC5A: 57600bps FC4A: 19200bps FC5A: 57600bps FC4A: 19200bps FC5A: 57600bps FC4A: 19200bps (38400 bps 1) Maintenance Communication Possible Possible Possible User Communication Possible — Possible 2 Data Link Communi- cation — — Possible Half-duplex Com- munication — — Possible Maximum Cable Length Special cable 3 Special cable 4 200 m Quantity of Slave Stations ——31 Isolation between Internal Circuit and Communication Port Not isolated Recommended Cable for RS485 — Twisted-pair shielded cable with a minimum core wire of 0.3 mm2 Conductor Resistance 85Ω/km maximum Shield Resistance 20Ω/km maximum 1. Maximum speed when data link is used. 2. FC5A (all types), FC4A-D20RK1, FC4A-D20RS1, FC4A-D40K3, FC4A-D40S3 3. FC2A-KC4C, FC2A-KM1C, FC4A-KC1C, FC4A-KC2C, FC2A-KP1C 4. FC2A-KP1C HMI Module (Optional) Part Number FC4A-PH1 Power Voltage 5V DC (supplied from the CPU module) Weight 20g Memory Cartridge Specifications (Optional) Part Number FC4A-PM32 FC4A-PM64 Memory EEPROM Accessible Memory Capacity 32 KB 64 KB Hardware for Storing Data CPU Module Software for Storing Data WindLDR Quantity of Stored Programs One user program can be stored on one memory cartridge Clock Cartridge (Optional) Part Number FC4A-PT1 Accuracy ±30 sec/month (typical) at 25ºC Backup Duration Approx. 30 days (typical) at 25ºC after backup battery fully charged Battery Lithium secondary battery Charging Time Approx. 10 hours for charging from 0% to 90% of full charge Replaceability N/A |
|
