AP2141/AP2151

0.5A SINGLE CHANNEL CURRENT-LIMITED POWER

SWITCH

AP2141/AP2151 Rev. 6

2 of 19

JUNE 2009

DS31562

www.diodes.com

AP 21 X 1 XX G - X

4 : Active Low

5 : Active High

G : Green

7/13 : Tape & Reel

1 : 1 Channel

Channel

Green

Package

Enable

Packing

W : SOT25

S : SOP-8L

MP : MSOP-8L-EP

FM : DFN2018-6

Device

Package

Code

Packaging

(Note 2)

7”/13” Tape and Reel

Quantity

Part Number Suffix

AP21X1WG-7

W

SOT25

3000/Tape & Reel

-7

AP21X1SG-13

S

SOP-8L

2500/Tape & Reel

-13

AP21X1MPG-13

MP

MSOP-8L-EP

2500/Tape & Reel

-13

AP21X1FMG-7

FM

DFN2018-6

3000/Tape & Reel

-7

Notes:

1. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied. Please visit our website at

http://www.diodes.com/products/lead_free.html

2. Pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which can be found on our website at

http://www.diodes.com/datasheets/ap02001.pdf.

Ordering Information
