7 / 19 page  AP2141/AP2151 0.5A SINGLE CHANNEL CURRENT-LIMITED POWER SWITCH AP2141/AP2151 Rev. 6 7 of 19 JUNE 2009 DS31562 www.diodes.com © Diodes Incorporated Typical Performance Characteristics (Continued) Short Circuit Current, Device Enabled Into Short 500us/div Inrush Current 1ms/div 3 Ω Load Connected to Enabled Device 2ms/div 2 Ω Load Connected to Enabled Device 2ms/div Short Circuit with Blanking Time and Recovery 20ms/div Power On 1ms/div Iout 200mA/div Ven 5V/div Iout 200mA/div VIN=5V TA=25°C CL=22uF Ven 5V/div VIN=5V TA=25°C RL=10Ω CL=470uF CL=220uF CL=100uF Iout 500mA/div Vflag 2V/div VIN=5V TA=25°C CL=22uF Iout 500mA/div Vflag 2V/div VIN=5V TA=25°C CL=22uF Iout 1A/div Vout 5V/div Vin 5V/div Vflag 5V/div TA=25°C CL=22uF RL=10Ω VIN=5V TA=25°C CL=22uF Vflag 5V/div Iout 200mA/div Ven 5V/div |
|
|
