background image
THERMAL DATA
Rthj-ca se
Thermal Resistance Junction-case
Max
2.5
oC/W
ELECTRICAL CHARACTERISTICS (Tcase =25
oC unless otherwise specified)
Symb ol
Parameter
Test Cond ition s
Mi n.
Typ .
Max.
Un it
ICES
Collect or Cut-off
Current (VBE =0)
VCE =1500 V
TC =125
oC
VCE =1500 V
1
2
mA
mA
IEBO
Emitt er Cut-off Current
(IC =0)
VEB =5 V
100
µA
VCEO(sus )
∗ Collector-Emitter
Sustaining Voltage
(IB =0)
IC = 100 mA
700
V
VEBO
Emitt er Base Voltage
(IC =0)
IE =10 mA
10
V
VCE(sat)
∗ Collector-Emitter
Saturat ion Voltage
IC =4. 5 A
IB =2 A
1
V
VBE(s at)
∗ Base-Emitter
Saturat ion Voltage
IC =4.5 A
IB =2 A
1.3
V
ts
tf
INDUCTIVE LOAD
St orage Time
Fall T ime
IC =4. 5 A
hFE =2.5
VCC =140 V
LC =0. 9 mH
LB =3
µH
7
0. 55
µs
µs
fT
Transit ion F requency
IC =0. 1 A
VCE =5 V
f =5 MHz
7
MHz
∗ Pulsed: Pulse duration = 300 µs, duty cycle 1.5 %
Safe Operating Area.
Thermal Impedance
S2000AFI
2/6
