Data Sheet
ADAR4002
TERMINOLOGY
analog.com
Rev. A | 39 of 66
Time Delay Range
The time delay range is the total available time delay of the TDU.
The time delay is user programmable to either 508 ps or 254 ps via
Bit 7 of each TDxx register.
Time Delay Unit (TDU)
The TDU is used in the ADAR4002 to set the time delay.
TDU and DSA
The TDU and DSA are the variable time delay and attenuation
block that includes one DSA and one TDU.
Update Command
The update command is a command that advances the selected
sequencer while in SPI mode.
Variable Amplitude and Phase (VAP) Block
The VAP block is a block that contains a programmable TDU and
DSA.
VAP Vector
The VAP vector is the 14 bits of combined data that make up a
single TDU and DSA state.
