DS6638 Rev 36

47/54

M24C64-W M24C64-R M24C64-F M24C64-DF

Ordering information

Table 29. Ordering information scheme

Example:

M24C64

-D

W MC 6

P /P F

Device type

M24 = I2C serial access EEPROM

Device function

C64 = 64 Kbit (8192 x 8 bit)

Device family

Blank = Without Identification page

D = With Identification page

Operating voltage

W = VCC = 2.5 V to 5.5 V

R = VCC = 1.8 V to 5.5 V

F = VCC = 1.7 V to 5.5 V

Package

BN = PDIP8(1)

1. RoHS-compliant (ECOPACK1®)

MN = SO8 (150 mil width)(2)

2. ECOPACK2® ((RoHS compliant and free of brominated, chlorinated and antimony oxide flame retardants))

DW = TSSOP8 (169 mil width)(2)

MC = UFDFPN8 (DFN8)(2)

MH = UFDFPN5 (DFN5)(2)

CS = 5-bump WLCSP(2)

CT = 8-bump WLCSP(2)

CU = 4-bump WLCSP

Device grade

6 = Industrial: device tested with standard test flow over –40 to 85 °C

Option

T = Tape and reel packing

blank = tube packing

Plating technology

P or G = ECOPACK2®

Process(3) or Packing option

3. The process letter is used only when ordering WLCSP packages, the process letter is not specified when

ordering any other package. These process letters appear on the device package (marking) and on the

shipment box. Please contact your nearest ST Sales Office for further information.

/P or /K or /T = Manufacturing technology code

/12 = Packing 12 mm tape

Option

Blank = No Back Side Coating

F = Back Side Coating (WLCSP height = 0.345mm)
