Table 22. UFDFPN8 - Mechanical data

Symbol

millimeters

inches(1)

Min

Typ

Max

Min

Typ

Max

0.450

0.550

0.600

0.0177

0.0217

0.0236

0.000

0.020

0.050

0.0000

0.0008

0.0020

b(2)

0.200

0.250

0.300

0.0079

0.0098

0.0118

1.900

2.000

2.100

0.0748

0.0787

0.0827

1.200

1.600

0.0472

0.0630

2.900

3.000

3.100

0.1142

0.1181

0.1220

1.200

1.600

0.0472

0.0630

0.500

0.0197

0.300

0.0118

0.300

0.500

0.0118

0.0197

0.150

0.0059

0.300

0.0118

aaa

0.150

0.0059

bbb

0.100

0.0039

ccc

0.100

0.0039

ddd

0.050

0.0020

eee(3)

0.080

0.0031

1. Values in inches are converted from mm and rounded to four decimal digits.

2. Dimension b applies to plated terminal and is measured between 0.15 and 0.30 mm from the terminal tip.

3. Applied for exposed die paddle and terminals. Exclude embedding part of exposed die paddle from measuring.

Figure 28. UFDFPN8 - Recommended footprint

0.500

1.400

0.600

1.200

0.300

1.300

Dimensions are expressed in millimetres.

M95256-W M95256-R M95256-DF

UFDFPN8 (DFN8) package information

DS4712 - Rev 22

page 39/51
