Symbol

Test Conditions

Maximum Ratings

V

DSS

T

J

= 25

C to 150C

250

V

DGR

T

J

= 25

C to 150C, R

GS = 1M

250

V

GSS

Continuous

 20

V

GSM

Transient

 30

V

I

D25

T

C = 25C (Chip Capability)

240

A

I

L(RMS)

External Lead Current Limit

200

A

I

DM

T

C = 25C, Pulse Width Limited by TJM

600

A

I

A

T

C = 25C

200

A

E

AS

T

C = 25C3

J

P

D

T

C = 25C

695

W

dv/dt

I

S

 I

DM, VDD  VDSS, TJ  150°C

20

V/ns

T

J

-55 ... +150

C

T

JM

150

C

T

stg

-55 ... +150

C

V

ISOL

50/60 Hz, RMS

t = 1 minute

2500

V~

I

ISOL  1mA

t = 1 second

3000

V~

M

d

Mounting Torque

1.5/13

Nm/lb.in

Terminal Connection Torque

1.3/11.5

Nm/lb.in

Weight

30

g

Symbol

Test Conditions

Characteristic Values

(T

J = 25C Unless Otherwise Specified)

Min.

Typ.

Max.

BV

DSS

V

GS = 0V, ID = 3mA

250

V

GS(th)

V

DS = VGS, ID = 8mA

2.5

4.5

V

I

GSS

V

GS =  20V, VDS = 0V

200 nA

I

DSS

V

DS = VDSS, VGS = 0V

25

A

T

J = 125C

2.5 mA

R

DS(on)

V

GS = 10V, ID = 120A, Note 1

3.5

4.5 m



IXFN240N25X3

V

DSS

= 250V

I

D25

= 240A

R

DS(on) 

 4.5m



DS100841B(9/18)

N-Channel Enhancement Mode

Avalanche Rated

Fast Intrinsic Diode

X3-Class HiPerFETTM

Power MOSFET

Features



International Standard Package



miniBLOC, with Aluminium Nitride

Isolation



Isolation Voltage 2500V~



High Current Handling Capability



Fast Intrinsic Diode



Avalanche Rated



Low R

DS(on)

Advantages



High Power Density



Easy to Mount



Space Savings

Applications



Switch-Mode and Resonant-Mode

Power Supplies



DC-DC Converters



PFC Circuits



AC and DC Motor Drives



Robotics and Servo Controls

miniBLOC, SOT-227



E153432

G

D

S

G = Gate

D = Drain

S = Source

S

D

G

Preliminary Technical Information
