Wall Plug – Ins - Interchangeable

Web: www.TriadMagnetics.com

Phone 951-277-0757

Fax 951-277-2757

460 Harley Knox Blvd.

Perris, California 92571

Publish Date: September 29, 2016

WSX120-2000-R13

Electrical Specifications (@25C)

1. Input Voltage rating: 100-240VAC, 50-60Hz

2. Input Voltage range: 90-264VAC

3. Input current: 0.8A(RMS) @ 115VAC

4. Max Inrush Current: 50A @ 115VAC (Cold start)

5. Output Voltage: 12.0VDC

6. Output Current: 2.0A

7. Regulation (line & load): ±5%

8. Ripple: 150mVpk-pk Max

9. No load power (stand by): < 100 mW

10. Average Efficiency: 86% Typ. Meets minimum level

VI

Environmental Specifications

1. Operating Temperature Range: 0°C to +45° C @ full load

2. Storage Temperature Range: -20°C to 60°C

3. Humidity: 5% to 95%, Non-condensing

Reliability Specifications

1. Leakage Current: <0.25mA (264VAC)

2. Dielectric Strength (Hi-pot): 4242VDC/3secs., 5mA Max

3. Warranty: 5 years

Mechanical Parameters

Case Type: Thermoplastic molded enclosure.

Output Cord: 20 AWG, 6 Ft. Long Nom.

Safety & EMI

ETL: UL/ANSI 60950 Class

II, Double Insulated

BS: 1363-1:1995 + A1:1997 + A2:2003 + A3:2007

AS/NZS: AS/NZS 60950.1:2011 + A1, AS/NZS 60065:2012

GS (S50311479): EN 60950-1: 2006 + A11+A1+A12+A2

EMI standard: FCC part 15 class B, EN 61204-3:2000

Over voltage and short circuit protected

EISA 2007/CEC Compliance: This power supply meets the minimum efficiency

requirements per Department of Energy and California Energy Commission.

RoHS Compliance: Meets the requirements of 2011/65/EU, known as

the RoHS initiative.

Upon printing, this document is considered “uncontrolled”. Please

contact Triad Magnetics’ website for the most current version.

Dim.: mm

North America

European Union

United Kingdom

Australia/New Zealand

RoHS

2011/65/EU

VI
