34 / 274 page  Mitsubishi microcomputers M16C / 62A Group SINGLE-CHIP 16-BIT CMOS MICROCOMPUTER Bus Control 34 Figure 1.9.6. Typical bus timings using software wait Output Input Address Address < Separate bus (with wait) > BCLK Read signal Write signal Data bus BCLK Read signal Address bus/ Data bus Chip select (Note 2) Address Address Data output Address Address Input ALE < Multiplexed bus > Write signal BCLK Read signal Write signal Address bus (Note 2) Address Address Bus cycle (Note 1) < Separate bus (no wait) > Output Data bus Input Note 1: These example timing charts indicate bus cycle length. After this bus cycle sometimes come read and write cycles in succession. Note 2: The address bus and chip select may be extended depending on the CPU status such as that of the instruction queue buffer. Bus cycle (Note 1) Bus cycle (Note 1) Bus cycle (Note 1) Bus cycle (Note 1) Bus cycle (Note 1) Address bus (Note 2) Address bus (Note 2) Chip select (Note 2) Chip select (Note 2) |
|
