FT51A Advanced MCU with 8051 Compatible Core IC Datasheet

Version 1.5

Doc ument N o.: FT _000877

C learance N o.: FT DI#420

1 Typical Applications



USB Data Acquisition



General Purpose Microcontroller



Sensor and Monitoring control



Mass storage data transfers across all

segments, including medical, industrial data-

logger, power-metering, and test

instrumentation



USB to RS232/RS422/RS485 Converters



Incorporate USB interface to enable PC

transfers for development systems



Interfacing MCU/PLD/FPGA based designs to

add USB connectivity



Industrial equipment control systems



POS systems



USB Bar Code Readers



Internet of things application



Home automation control systems

1.1 Part Numbers

Part Number

Package

FT51AQ-R

48 Pin QFN, body 7x7x0.75 mm, pitch 0.5mm, Taped and Reel, 3000 per reel

FT51AQ-T

48 Pin QFN, body 7x7x0.75 mm, pitch 0.5mm, Tray packing, 490 per tray

FT51AL-R

44 Pin LQFP, body 10x10x1.4 mm, pitch 0.8mm, Taped and Reel, 1000 per reel

FT51AL-T

44 Pin LQFP, body 10x10x1.4 mm, pitch 0.8mm, Tray packing, 160 per tray

FT51BQ-R

32 Pin QFN, body 6x6x0.75 mm, pitch 0.5mm, Taped and Reel, 3000 per reel

FT51BQ-T

32 Pin QFN, body 6x6x0.75 mm, pitch 0.5mm, Tray packing, 490 per tray

FT51CS-R

28 Pin SSOP, body 10.2x5.3x1.75 mm, pitch 0.65mm, Taped and Reel, 2000 per reel

FT51CS-U

28 Pin SSOP, body 10.2x5.3x1.75 mm, pitch 0.65mm, Tube packing, 47 per tube

Table 1-1 – Part Numbers

1.2 USB Compliant

The FT51A is fully compliant with the USB 2.0 specification and has been given the USB-IF Test-ID (TID)

40001701 (Rev C).
