ZSLS7031 Datasheet

© 2016 Integrated Device Technology, Inc.

5

January 26, 2016

1

IC Characteristics

Stresses beyond those listed under “Absolute Maximum/Minimum Ratings” (section 1.1) may cause permanent

damage to the device. These are stress ratings only, and functional operation of the device at these or any other

conditions beyond those recommended under “Operating Conditions” (section 1.2) is not implied. Exposure to

absolute maximum conditions for extended periods may affect device reliability.

1.1

Absolute Maximum/Minimum Ratings

Table 1.1

Absolute Maximum Ratings

No.

PARAMETER

SYMBOL

CONDITIONS

MIN

TYP

MAX

UNIT

1.1.1

VCC to GND

-0.3

24

V

1.1.2

VSINE, FSET, NC, CS, FB

-0.3

5.5

V

1.1.3

VCC input current

10

mA

1.1.4

ESD performance

Human Body Model (HBM)

based on MIL 883-H,

Method 3015.8

±2

kV

1.1.5

Junction temperature

150

°C

1.1.6

Storage temperature

-65

150

°C

1.2

Operating Conditions

Table 1.2

Operating Conditions

No.

PARAMETER

SYMBOL

CONDITIONS

MIN

TYP

MAX

UNIT

1.2.1

Operating temperature

-45

105

°C

1.2.2

VCC voltage range

9

22

V
