2 / 3 page

UB9K

DUAL TRANSISTOR

UNISONICTECHNOLOGIESCO.,LTD

2 of 3

www.unisonic.com.tw

QW-R218-031.A



ABSOLUTE MAXIMUM RATING

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

VCC

-50

Input Voltage

VIN

-40 ~ +6

IOUT

-70

Output Current

IC(MAX)

-100

Power Dissipation

150

Junction Temperature

+150

°C

Storage Temperature

TSTG

-55 ~ +150

°C

Note Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



ELECTRICAL CHARACTERISTICS (TA=25°C, unless otherwise specified)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

VIN(OFF)

VCC=-5V, IOUT=-100μA

-0.3

Input Voltage

VIN(ON)

VOUT=-0.3V, IOUT=-1mA

-1.4

Output Voltage

VOUT (ON) IOUT/IIN=-5mA/-0.25mA

-0.1

-0.3

Input Current

IIN

VIN=-5V

-0.88

Output Current

IOUT(OFF) VCC=-50V, VIN=0V

-0.5

μA

DC Current Gain

hFE

VOUT=-5V, IOUT=-5mA

Input Resistance

KΩ

Resistance Ratio

R2/R1

3.7

4.7

5.7

Transition Frequency

VCE=-10V, IE=5mA, f=100MHz(Note)

250

MHz

Note: Transition frequency of the device.
