RB520S40
Preliminary
SCHOTTKY DIODE
UNISONICTECHNOLOGIESCO.,LTD
2 of 3
www.unisonic.com.tw
QW-R202-061.a
ABSOLUTE MAXIMUM RATINGS (Single Diode @ TA=25°C, unless otherwise specified)
PARAMETER
SYMBOL
RATINGS
UNIT
Peak Repetitive Reverse Voltage
VRRM
40
V
Working Peak Reverse Voltage
VRWM
40
V
DC Blocking Voltage
VR
40
V
Forward Continuous Current
IFM
250
mA
Non-repetitive Peak Forward Surge Current (Note 3)
IFSM
1.0
A
Junction Temperature
TJ
+125
°C
Storage Temperature
TSTG
-55 ~ +125
°C
Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
ELECTRICAL CHARACTERISTICS (TA=25°C, unless otherwise specified)
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX UNIT
IF=20mA
0.37
V
Forward Voltage Drop
VF
IF=200mA
0.60
V
VR=10V
1.00
μA
Reverse Leakage Current
IR
VR=30V
5.00
μA
Total Capacitance
CT
VR=0V, f=1.0MHz
50
pF
Reverse Recovery Time
tRR
IF=IR=200mA, IRR=0.1×IR,
RL=100Ω
10
ns
Note: Pulse width ≤ 300μs, duty cycle ≤ 2%.
