ADP5071
Data Sheet
Rev. A | Page 8 of 27
TYPICAL PERFORMANCE CHARACTERISTICS
Typical performance characteristics are generated using the standard bill of materials for each input/output combination listed in Table 9,
Table 10, and Table 11.
1200
0
200
400
600
800
1000
0
10
20
30
40
50
VPOS (V)
VIN = 3.3V, L = 3.3µH
VIN = 3.3V, L = 4.7µH
VIN = 5V, L = 3.3µH
VIN = 5V, L = 4.7µH
VIN = 12V, L = 10µH
VIN = 15V, L = 10µH
Figure 4. Boost Regulator Maximum Output Current, fSW = 1.2 MHz,
TA = 25°C, Based on Target of 70% ILIM (BOOST)
1000
0
200
400
800
600
0
10
20
30
40
50
VPOS (V)
VIN = 3.3V, L = 3.3µH
VIN = 3.3V, L = 4.7µH
VIN = 5V, L = 2.2µH
VIN = 5V, L = 4.7µH
VIN = 12V, L = 4.7µH
VIN = 15V, L = 6.8µH
Figure 5. Boost Regulator Maximum Output Current, fSW = 2.4 MHz,
TA = 25°C, Based on Target of 70% ILIM (BOOST)
100
0
20
40
60
80
0.001
0.01
0.1
1
LOAD (A)
VIN = 3.3V, 1.2MHz
VIN = 3.3V, 2.4MHz
Figure 6. Boost Regulator Efficiency vs. Current Load, VIN = 3.3 V,
VPOS = 5 V, TA = 25°C
1000
0
200
400
600
800
–40
–30
–20
–10
0
VNEG (V)
VIN = 3.3V, L = 4.7µH
VIN = 5V, L = 6.8µH
VIN = 5V, L = 10µH
VIN = 12V, L = 6.8µH
VIN = 12V, L = 15µH
VIN = 15V, L = 10µH
VIN = 3.3V, L = 6.8µH
VIN = 15V, L = 22µH
Figure 7. Inverting Regulator Maximum Output Current, fSW = 1.2 MHz,
TA = 25°C, Based on Target of 70% ILIM (INVERTER)
700
0
100
200
300
400
500
600
–40
–30
–20
–10
0
VNEG (V)
VIN = 3.3V, L = 2.2µH
VIN = 5V, L = 3.3µH
VIN = 5V, L = 4.7µH
VIN = 12V, L = 6.8µH
VIN = 15V, L = 10µH
VIN = 12V, L = 3.3µH
VIN = 15V, L = 4.7µH
Figure 8. Inverting Regulator Maximum Output Current, fSW = 2.4 MHz,
TA = 25°C, Based on Target of 70% ILIM (INVERTER)
100
0
20
40
60
80
0.001
0.01
0.1
1
LOAD (A)
VIN = 3.3V, 1.2MHz
VIN = 3.3V, 2.4MHz
Figure 9. Inverting Regulator Efficiency vs. Current Load, VIN = 3.3 V,
VNEG = −5 V, TA = 25°C
