2 / 3 page

6-φ0.8∼1.0

5-φ0.8∼1.0

8-φ0.8∼1.0

5-φ0.8∼1.0

Switching

function

Part No.

★FP2F−5M−Z

（ON）

Connecting terminals

−3

−6

−1

−4

SPDT

DPDT

Switching

function

Part No.

FP1F

−2M−Z

（ON）

Connecting terminals

−32−1

Switching

function

Part No.

★FP2F−2M−Z

（ON）

Connecting terminals

−3

−6

−1

−4

Switching

function

Part No.

FP1F

−5M−Z

（ON）

Connecting terminals

−32−1

R/A

Terminal numbers are not shown on the switch.

PC Hole Layouts

（Top view）

PC Hole Layouts

（Top view）

PC Hole Layouts

（Top view）

PC Hole Layouts

（Top view）

■Optional Accessories

《Sold separately》

■Color Cap Mounting

Part Name

Dimension

Color

Part Number

Coor Cap

Gloss Änish

White

140000481453

Red

140000481452

ABS resin

Black

140000481451

Gray

140000481450

（ON）

：Momentary.

★：Made to order products.

The blue line shows the outline of the switch.

：Optional Accessories.
