Limitron® fast-acting, RK1 – 250 volt fuses

Catalog symbol - KTN-R-(amps)

Description:

Advanced protection Class RK1 current-limiting,

fast-acting fuses.

Specifications:

Ratings

•

Volts:

•

250 Vac

•

250 Vdc (70-350 A)

•

Amps - 1-600 A

•

Interrupting rating:

•

200 kA Vac RMS Sym.

•

100 kA Vdc

Agency Information

•

UL® Listed, Std. 248-12, Guide JDDZ,

File E54273

•

CSA® Certified, Class 1422-02, File 53787

•

CE

Features:

•

Provides 10X better current limitation to help

prevent equipment damage caused by

short-circuit events

•

200 kA interrupting rating complies with

NEC® Section 110.9 for today’s large capacity

systems

•

Fast-acting fuse helps prevent equipment

damage caused by short-circuit events

•

Incorporates Class R rejection feature. Can

be inserted in non-rejection type fuse holders

to physically and electrically replace Class H,

K1, K5, and other fast-acting fuses

•

Ideal for critical industrial or commercial

applications that have specific current

limitation requirements

Dimensions - in:

450 A to 600 A

10.38"

110 A to 200 A

7.13"

225 A to 400 A

8.63"

70 A to 100 A

5.88"

1/10 A to 30 A

0.56"

2"

35 A to 60 A

0.81"

3"

1.06"

1.56"

2.06"

2.59"

Catalog numbers

KTN-R-1

KTN-R-30

KTN-R-125

KTN-R-2

KTN-R-35

KTN-R-150

KTN-R-3

KTN-R-40

KTN-R-175

KTN-R-4

KTN-R-45

KTN-R-200

KTN-R-5

KTN-R-50

KTN-R-225

KTN-R-6

KTN-R-60

KTN-R-250

KTN-R-8

KTN-R-70

KTN-R-300

KTN-R-10

KTN-R-75

KTN-R-350

KTN-R-12

KTN-R-80

KTN-R-400

KTN-R-15

KTN-R-90

KTN-R-450

KTN-R-20

KTN-R-100

KTN-R-500

KTN-R-25

KTN-R-110

KTN-R-600

Technical Data 1043

Effective May 2016

Supersedes October 2002

BUSSMANN

SERIES
