TMS320C31PQL60 датащи(PDF) 47 Page - Texas Instruments |
|
|
|||||||||||||||||||||||||||||
TMS320C31PQL60 датащи(HTML) 47 Page - Texas Instruments |
|
|
47 / 48 page  TMS320C31, TMS320LC31 DIGITAL SIGNAL PROCESSORS SPRS035B – MARCH 1996 – REVISED JANUARY 1999 47 POST OFFICE BOX 1443 • HOUSTON, TEXAS 77251–1443 MECHANICAL DATA PQ (S-PQFP-G***) PLASTIC QUAD FLATPACK 100 LEAD SHOWN 88 0.012 (0,30) 0.008 (0,20) 64 0.025 (0,635) Seating Plane 132 1.090 (27,69) 1.070 (27,18) 0.966 (24,54) 0.934 (23,72) 1.112 (28,25) 1.088 (27,64) 0.800 (20,32) 4040045 / C 11/95 100 1 13 63 39 ”D2” SQ ”D1” SQ ”D” SQ 14 ”D3” SQ 38 DIM ”D” ”D2” ”D3” ”D1” NOM MIN MAX MIN MAX MIN MAX LEADS *** 0.180 (4,57) MAX 100 0.890 (22,61) 0.870 (22,10) 0.766 (19,46) 0.734 (18,64) 0.912 (23,16) 0.888 (22,56) 0.600 (15,24) 0.004 (0,10) M 0.006 (0,15) 0.010 (0,25) 0.020 (0,51) MIN 0.130 (3,30) 0.150 (3,81) 0.006 (0,16) NOM Gage Plane 0.036 (0,91) 0.046 (1,17) 0 °–8° 89 NOTES: A. All linear dimensions are in inches (millimeters). B. This drawing is subject to change without notice. C. Falls within JEDEC MO-069 |
|
