VLB10050 Type

PACKAGING STYLE

REEL DIMENSIONS

* These values are typical values.

TAPE DIMENSIONS

Type

A

W1

W2

N

E

VLB10050

ø330

25.5

30.4

ø100

2

ø13.0

±0.5

ø21.0

±0.8

2.0

±0.5

A

(1.0)

Dimensions in mm

E

W2

W1

P0

P2

øD0

P1

A

t

K

Dimensions in mm

Type

A

B

øD0

E

F

P0

P1

P2

W

K

t

VLB10050

7.2

10.4

1.5+0.1/-1

1.75±0.1

11.5±0.1

4.0±0.1 12.0±0.1 2.0±0.1 24.0±0.3

5.2

0.5
