4

Part No.

U.FL-R-SMT(01)

U.FL-R-SMT(10)

CL No.

331-0471-0-01

331-0471-0-10

Packaging

Bag packaging (100 pieces/bag)

Reel packaging (2500 pieces/reel)

Weight (mg)

15.7/unit

sReceptacles

Note 1: Receptacles of (01) specification are sold by the

pack with 100 pieces per pack.

Please order in pack units.

Note 2: Receptacles of (10) specification are sold by the

reel (which contains 2,500 pieces).

Please order in reel units.

Note 3: Permissible value for mold resin which gets onto

the center contact.

qPackaging Specifications

Embossed Carrier Tape Dimensions

Reel Dimensions

GND

GND

GND

GND

Cut Out Prohibition Area

Recommended PCB Footprints

SIG

SIG

Ø2

3

2.6

0.6

1

±0.05

4

±0.05

1.9

±0.05

8

±0.1

2

±0.1

4

±0.1

0.3

1.6

Center contact

Unreeling direction

1.8

14

Ø13

Ø21
