background image
JH463480854A
VER: 1.0
- 9 -
Issue date: 2013/08/12
JEWEL HILL ELECTRONIC CO.,LTD.
7.Pin Description
Pin NO.
Symbol
Description
1
NC
No connection
2
NC
No connection
3
NC
No connection
4
NC
No connection
5
CS
Chip select pin
6
RS
Display data / command selection
7
WR
Write signal
8
GND
Ground
9
RD
Read signal
10
GND
Ground
11~18
D7~D0
Data bus
19
NC
No connection
20
NC
No connection
21~28
D15~D8
Data bus
29
RESET
Reset pin
30
TE
Tearing effect output pin
31
NC
No connection
32
GND
Ground
33
NC
No connection
34
NC
No connection
35
GND
Ground
36
VCC
Power supply for analog circuit(2.8V)
37
IOVCC
Power supply for digital circuit(2.8V/1.8V)
38
K
LED-
39
A
LED+
