JH50480800B
VER: 1.0
- 9 -
Issue date: 2013/08/15
JEWEL HILL ELECTRONIC CO.,LTD.
7.Pin Description
Pin NO.
Symbol
Description
1
GND
GROUND
2
LEDA
LED+
3
LEDK
LED-
4
NC
NC
5
NC
NC
6
NC
NC
7
NC
NC
8
NC
NC
9
GND
GROUND
10
IOVCC
The
power supply 1.8/2.8V
11
VCC
The
power supply 2.8V
12
GND
GROUND
13
NC
NC
14
CS
Chip select input pin
15
RS
Command/data select
16
WR
Write execution control pin
17
RD
Read execution control pin
18
RESET
RESET pin
19
FMARK
Frame head pulse signal output pin
20
GND
GROUND
21
GND
GROUND
22~37
DB15~DB0
Data Bus
38
GND
GROUND
39
LEDPWM
Back light control pin
40
GND
GROUND
