10 / 23 page  JH43540960A VER: 1.0 - 9 - Issue date: 2013/08/15 JEWEL HILL ELECTRONIC CO.,LTD. 7.Pin Description Pin NO. Symbol Description 1 LED_K LED- 2 LED_A LED+ 3 MTP NC 4 VDD Power Supply2.8V 5-7 GND Ground 8 LANSEL NC 9 DSWAP0 NC 10 DSWAP1 NC 11 PSWAP NC 12-14 IM3,1M1,IM0 NC 15 TE（FMARK） Tearing effect output pin 16~17 SDA，SCL NC 18 RESET System Reset Pin 19 VDDI Power Supply(2.8V/1.8V) 20 GND Ground 21 LEDPWM Control singal for brihtness of the LED backlight 22 LEDON Control signal for LED is on/off 23 VDD Power Supply2.8V 24 GND Ground 25~26 D22P，D22N NC 27 GND Ground 28 D1P Data signals if MIPI interface is used 29 D1N Data signals if MIPI interface is used 30 GND Ground 31 CLKP Clock signals if MIPI interface is used 32 CLKN Clock signals if MIPI interface is used 33 GND Ground 34 D0P Data signals if MIPI interface is used 35 D0N Data signals if MIPI interface is used 36 GND Ground 37~38 D21P，D21N NC 39 GND Ground |
|
|
