JH32240400E

VER: 1.0

- 3 -

Issue date: 2013/08/12

JEWEL HILL ELECTRONIC CO.,LTD.

1. GENERAL DESCRIPTION.

The JH32240400E model is a Color TFT LCD. This main Module has a 3.2 inch diagonally measured

active display area with 240(RGB)×400 resolution. Each pixel is divided into Red, Green and Blue

sub-pixels and dots which are arranged in vertical stripes.

The LCD color is determined with 262,000 colors signal for each pixel.

The JH32240400E has been designed to apply the interface method that enables low power, high

speed, and high contrast.

The JH32240400Eis intended to support applications where thin thickness, wide viewing angle and

low power are critical factors and graphic displays are important.

2. GENERAL FEATURES.

Item

Display Panel

Remark

Display Mode

Normally White, Transmissive LCD

Viewing Direction

6 O’CLOCK

Input Signals

8Bits

Outside Dimensions

47.66mm(W)*80.9mm(H)*3.55mm(T)

Effective Area

-

Active Area

41.76mm(W)×69.6mm(H)

Number of Pixels

240×RGB×400Pixels

Pixel Pitch

0.174mm(H)×0.174mm(W)

Pixel Arrangement

RGB Vertical stripes

Drive IC

ILI9327

3.Absolute Maximum Ratings

The following are maximum values which, if exceeded may cause operation or damage to

the unit.

ITEM

Symbol

Min.

Typ.

Max.

Unit

Remark

Power for Circuit Driving

VDD

-0.3

-

3.3

V

Power for Circuit Logic

VCI

-0.3

-

4.6

V

LC Operating Voltage *1)

Vop

-

V

LED Forward Voltage

V

BBBBBBBBB

f

BBBBBBBBB

3.0

3.2

3.4

V

LED Forward Current

If

-

60

-

mA

LED Luminance

B

BBBBBBBBB

P

BBBBBBBBB

3200

-

-

cd/m

PPPPPPPPP

2

PPPPPPPPPPPPPPPPPPPPPPP

Storage Humidity

H

BBBBBBBBB

ST

BBBBBBBBB

10

-

90

%RH

Storage Temperature

T

BBBBBBBBB

ST

BBBBBBBBB

-30

-

80

℃

Operating Ambient Humidity

H

BBBBBBBBB

OP

BBBBBBBBB

10

-

90

%RH

Operating Ambient temperature

T

BBBBBBBBB

OP

BBBBBBBBB

-20

-

70

℃

At

25±5℃
