3.ABSOLUTE MAXIMUM RATINGS.

The following are maximum values which, if exceeded may cause operation or damage to

the unit.

ITEM

Symbol

Min.

Typ.

Max.

Unit

Remark

Power for Circuit Driving

VDD

-0.3

-

3.3

V

Power for Circuit Logic

VCI

-0.3

-

5.0

V

LED Forward Voltage

V

BBBBBBBBB

f

BBBBBBBBB

3.0

3.2

3.4

V

LED Forward Current

IF

-

60

-

mA

LED Luminance

B

BBBBBBBBB

P

BBBBBBBBB

3200

-

-

cd/m

PPPPPPPPP

2

PPPPPPPPPPPPPPPPPPPPPPP

Storage Humidity

H

BBBBBBBBB

ST

BBBBBBBBB

10

-

90

%RH

Storage Temperature

T

BBBBBBBBB

ST

BBBBBBBBB

-30

-

80

℃

Operating Ambient Humidity

H

BBBBBBBBB

OP

BBBBBBBBB

10

-

90

%RH

Operating Ambient temperature

T

BBBBBBBBB

OP

BBBBBBBBB

-20

-

70

℃

At

25±5℃

Note:

*1)

Liquid Crystal driving voltage.

Due to the characteristics of LC Material, this voltage vary with environmental

temperature.

*2) Temp.>60℃, Absolute humidity shall be less than 90%RH at 60℃

*3) Temp.≤60℃, 90%RH MAX.

4.ELECTRICAL CHARACTERISICS.

(Unless specified, the ambient temperature Ta=25℃)

Properties

Sym.

Min

Typ.

Max

Unit

Note

Power for Circuit Driving

VDD

1.65

2.8

3.3

V

Note

Power for Circuit Logic

VCI

2.7

2.8

3.3

V

Note

BLU Driving Logic

Vbat

-

-

-

V

Low Voltage

VIL

0

-

0.2VDD

V

Logic Input

Voltage

High Voltage

VIH

0.8VDD

-

VDD

V

Low Voltage

VOL

0

-

0.1VDD

V

Logic Output

Voltage

High Voltage

VOH

0.9VDD

-

VDD

V

White

P

BBBBBBBBB

w

BBBBBBBBB

T.B.D

T.B.D

T.B.D

mW

Black

P

BBBBBBBBB

b

BBBBBBBBB

T.B.D

T.B.D

T.B.D

mW

Power

Consumption

Vertical Stripe

P

BBBBBBBBB

v

BBBBBBBBB

T.B.D

T.B.D

T.B.D

mW
