JH28240320B
VER: 1.0
- 9 -
Issue date: 2013/08/12
JEWEL HILL ELECTRONIC CO.,LTD.
7.Pin Description
Pin NO.
Symbol
Description
1
GND
GROUND
2
YD
Touch Panel Y-Down
3
XR
Touch Panel X-Right
4
YU
Touch Panel Y-Up
5
XL
Touch Panel X-Left
6
GND
GROUND
7~8
NC
NC
9
LEDK3
LEDK
10
LEDK4
LEDK
11
NC
NC
12
RESET
Reset
13-22
NC
NC
23-30
DB7-DB0
Data Bus
31
RD
Read signal
32
WR
Writer signal
33
RS
Data or command register select signal
34
CS
Chip select signal
35
GND
GROUND
36
IOVCC
Power supply(1.8/2.8v)
37~38
VCC
Power supply(2.8v)
39~40
NC
NC
41~42
LEDK1，LEDK2
LED-K
43
LEDA
LED-A
44
GND
GROUND
