Data Sheet

ADP1290

–40

–5

105

TEMPERATURE (°C)

ILOAD = 100mA

ILOAD = 200mA

ILOAD = 500mA

ILOAD = 1000mA

ILOAD = 2000mA

Figure 10. Ground Current vs. Temperature, Different Load Currents,

VIN = 13.2 V

100

1000

10000

ILOAD (mA)

VIN = 2.3V

VIN = 2.5V

VIN = 3.0V

VIN = 4.0V

VIN = 5.0V

VIN = 6.5V

VIN = 8.0V

VIN = 10.0V

VIN = 12.0V

VIN = 13.2V

Figure 11. Ground Current vs. Load Current (ILOAD), Different Input Voltages (VIN)

–50

–30

–10

110

TEMPERATURE (°C)

0.01

0.1

VIN = 2.3V

VIN = 2.5V

VIN = 3.0V

VIN = 4.0V

VIN = 5.0V

VIN = 6.5V

VIN = 8.0V

VIN = 10.0V

VIN = 12.0V

VIN = 13.2V

Figure 12. Ground Shutdown Current vs. Temperature, Output Open,

Different Input Voltages (VIN)

–50

–30

–10

110

TEMPERATURE (°C)

0.01

0.10

1.00

VIN = 2.3V

VIN = 2.5V

VIN = 3.0V

VIN = 4.0V

VIN = 5.0V

VIN = 6.5V

VIN = 8.0V

VIN = 10.0V

VIN = 12.0V

VIN = 13.2V

Figure 13. Ground Shutdown Current vs. Temperature, VOUT = 0 V,

Different Input Voltages (VIN)

CH1 2.00V BW CH2 1.00V BW M400µs

A CH4

1.04V

T 10.40%

INPUT CURRENT

OUTPUT

CH3

200mAΩ BW

Figure 14. Typical Turn On Time and Inrush Current, VIN = 2.3 V,

COUT = 100 μF, RLOAD = 100 Ω

CH1 2.00V BW

CH3

1.00AΩ BW

CH2 2.00V BW M400µs

A CH4

1.04V

T 10.40%

INPUT CURRENT

OUTPUT

Figure 15. Typical Turn On Time and Inrush Current, VIN = 6.5 V,

COUT = 100 μF, RLOAD = 100 Ω

Rev. 0 | Page 7 of 12
