Photoelectric sensors

G10, Through-beam photoelectric sensor

1) Average service life: 100,000 h at TU = +25 °C

Type

> GSE10-R3721

Part No.

> 1065913

At a glance

Long sensing ranges: up to 40 m

•

PinPoint LED with bright and precise light spot

•

With or without sensitivity adjustment

•

10 V DC ... 30 V DC or 24 V AC/DC … 240 V AC/DC power supply with

PNP/NPN or relay output

•

Small housing design

•

Rugged sensor housing with metal-reinforced holes for assembly

•

Weatherproof housing: ideal for outdoor applications

•

Your benefits

Long sensing ranges for maximum operating reserves

•

Universal DC or AC/DC power supply for even greater application flexibility

•

Highly reliable and durable despite optical interference or mechanical loads

•

Wide range of accessories simplifies sensor integration: aids for assembly and

connectors

•

Long service life even when used in outdoor applications thanks to rugged

weatherproof housing

•

Illustration may differ

Features

Sensor/detection principle:

Through-beam photoelectric sensor

Dimensions (W x H x D):

20 mm x 50 mm x 51.5 mm

Housing design (light emission):

Rectangular

Sensing range max.:

0 m ... 40 m

Sensing range:

0 m ... 35 m

Type of light:

Infrared light

Light source:

Wave length:

850 nm

Light spot size (distance):

Ø 433 mm (15 m)

Mechanics/electronics

Supply voltage:

Ripple:

Power consumption, sender:

≤ 2 VA

Power consumption, receiver:

≤ 2.5 VA
