21 / 59 page  EM359x Rev 1.0 21 3.7. RF Electrical Characteristics 3.7.1. Receive Table 3.8 lists the key parameters of the integrated IEEE 802.15.4-2003 receiver on the EM359x. Receive measurements were collected with the Silicon Labs EM359x Ceramic Balun Characterization Module (Version P1) at 2440 MHz. The typical number indicates one standard deviation above the mean, measured at room temperature (25 C). The Min and Max numbers were measured over process corners at room temperature. Table 3.8. Receive Characteristics Parameter Test Condition Min Typ Max Unit Frequency range 2400 — 2500 MHz Sensitivity (boost mode) 1% PER, 20 byte packet defined by IEEE 802.15.4-2003 — –102 — dBm Sensitivity 1% PER, 20 byte packet defined by IEEE 802.15.4-2003 — –100 — dBm High-side adjacent channel rejection IEEE 802.15.4-2003 interferer signal, wanted IEEE 802.15.4-2003 signal at –82 dBm — 35 — dB Low-side adjacent channel rejection IEEE 802.15.4-2003 interferer signal, wanted IEEE 802.15.4-2003 signal at –82 dBm — 35 — dB 2nd high-side adjacent channel rejec- tion IEEE 802.15.4-2003 interferer signal, wanted IEEE 802.15.4-2003 signal at –82 dBm — 46 — dB 2nd low-side adjacent channel rejection IEEE 802.15.4-2003 interferer signal, wanted IEEE 802.15.4-2003 signal at –82 dBm — 46 — dB High-side adjacent channel rejection Filtered IEEE 802.15.4-2003 inter- ferer signal, wanted IEEE 802.15.4- 2003 signal at –82 dBm — 39 — dB Low-side adjacent channel rejection Filtered IEEE 802.15.4-2003 inter- ferer signal, wanted IEEE 802.15.4- 2003 signal at –82 dBm — 47 — dB 2nd high-side adjacent channel rejection Filtered IEEE 802.15.4-2003 inter- ferer signal, wanted IEEE 802.15.4- 2003 signal at –82 dBm — 49 — dB 2nd low-side adjacent channel rejection Filtered IEEE 802.15.4-2003 inter- ferer signal, wanted IEEE 802.15.4- 2003 signal at –82 dBm — 49 — dB High-side adjacent channel rejection CW interferer signal, wanted IEEE 802.15.4-2003 signal at –82 dBm — 44 — dB Low-side adjacent channel rejection CW interferer signal, wanted IEEE 802.15.4-2003 signal at –82 dBm — 47 — dB |
|
