MBR10150C

DIODE

UNISONICTECHNOLOGIESCO.,LTD

2 of 3

www.unisonic.com.tw

QW-R601-039.D



ABSOLUTE MAXIMUM RATINGS (Per Diode Leg)

PARAMETER

SYMBOL

RATINGS

UNIT

DC Blocking Voltage

150

Peak Repetitive Reverse Voltage

VRRM

Working Peak Reverse Voltage

VRWM

Average Rectified Forward

Current (Rated VR) TC=142°C

Per Leg

Total

Peak Repetitive Forward Current

(Rated VR, Square Wave, 20 kHz) TC=142°C

IFRM

Non-Repetitive Peak Surge Current (Surge Applied At

Rated Load Conditions Half Wave, Single Phase, 60Hz)

IFSM

100

Voltage Rate of Change (Rated VR)

dv/dt

10000

V/µs

Operating Junction Temperature (Note 2)

150

°C

Storage Temperature

TSTG

-55 ~ 150

°C

Notes: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

2. The heat generated must be less than the thermal conductivity from Junction-to-Ambient: dPD/dTJ<1/θJA.



THERMAL DATA

PARAMETER

SYMBOL

RATINGS

UNIT

Junction to Ambient

θJA

°С/W

Junction to Case

TO-263

θJC

°С/W

TO-220F/TO-220F1

TO-220F2

4.5

°С/W



ELECTRICAL CHARACTERISTICS

PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

Instantaneous Forward Voltage Drop

(Note 1)

IF=5A, TC=25°C

0.92

IF=5A, TC=125°C

0.82

Instantaneous Reverse Current (Note 1)

Rated DC Voltage, TC=25°C

0.1

Rated DC Voltage, TC=125°C

15.0

Notes: Pulse Test: Pulse Width=300µs, Duty Cycle ≤ 2.0%.
