RCR2C

CMOS IC

UNISONICTECHNOLOGIESCO.,LTD

4 of 8

www.unisonic.com.tw

QW-R502-026.C



ABSOLUTE MAXIMUM RATING

PARAMETER

SYMBOL

RATINGS

UNIT

DC Supply Voltage

-0.3 ~ 6.0

V

Input/Output Voltage

V

Junction Temperature

125

°C

Operating Temperature

-20 ~ +85

°C

Storage Temperature

-40 ~ +150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



ELECTRICAL CHARACTERISTICS

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Supply Voltage

1.8

4.5

5.0

V

Operating Current

Unload

1.0

mA

Output Driving Current

Load=0.7V

4.5

mA

Oscillator Frequency Tolerance

-20

20

%



OUTPUT TABLES

FUNCTION KEY (UTC RCT2E)

DECODE RESULT (MOD = 1)

DECODE RESULT (MOD = 0)

END CODE

END CODE

FORWARDB (L)

FORWARD (H)

FORWARD (Z)

FORWARDB (L) & TURBOB (L)

FORWARD (H)

FORWARD (H) & TURBO (H)

TURBOB (L)

TURBO (H)

FORWARD (H) & TURBO (H)

TURBOB (L)& FORWARDB (L) & LEFTB (L)

FORWARD (H) & LEFT (H)

FORWARD (Z) & LEFT (H)

TURBOB (L) & FORWARDB (L) & RIGHTB (L)

FORWARD (H) & RIGHT (H)

FORWARD (Z) & RIGHT (H)

BACKWARDB (L)

BACKWARD (H)

BACKWARD (Z)

BACKWARDB (L) & RIGHTB (L)

BACKWARD (H) & RIGHT (H)

BACKWARD (Z) & RIGHT (H)

BACKWARDB (L) & LEFTB (L)

BACKWARD (H) & LEFT (H)

BACKWARD (Z) & LEFT (H)

LEFTB (L)

LEFT (H)

LEFT (H)

RIGHTB (L)

RIGHT (H)

RIGHT (H)

Note: L=LOW, H=HIGH, Z= 60Hz 50% DUTY Pulse.
