Automation Panels

Features

FPM-3191G

9U Rackmount 19" SXGA Industrial

Monitor with Resistive Touchscreen,

Direct-VGA and DVI Ports

Specifications

General

ƒ

Button Controls

OSD (Onscreen Display) control pad on front panel

ƒ

Certification

BSMI, CCC, CE, FCC Class A, UL

ƒ

Dimensions (W x H x D) 482mm x 399mm x 67 mm (18.98" x 15.71" x 2.64")

ƒ

Enclosure

Front panel: Aluminum with coating

Rear cover: Stainless steel chassis

*Mounting holes on rear cover are designed for PWR-246E DC Source

ƒ

Mounting

Panel, wall, desktop, VESA arm & 19" rackmount

ƒ

Power Input

DC Jack: e x ternal 57 W power adapter, with 100 ~ 240

Note: AC power adapter is included.

ƒ

Power Consumption

35 W + 20%

ƒ

Video Port

VGA & DVI-D port

ƒ

Weight (Net)

10.65 kg (23.46 Ibs)

LCD Display

ƒ

Display Type

SXGA TFT LCD with LED backlight

ƒ

Display Size

19"

ƒ

Max. Resolution

1280 x 1024

ƒ

Max. Color

16.7 M

ƒ

Viewing Angle (H/V°)

170/160

ƒ

350

ƒ

Backlight Life (hrs)

50,000

ƒ

Contrast Ratio

1000:1

ƒ 19" SXGA TFT LED LCD with 50,000 backlight life time

ƒ Robust design with stainless steel chassis and aluminum front panel

ƒ Anti-glare screen with tempered glass and IP65 certified front panel

ƒ Lockable OSD control pad on rear cover

ƒ Supports panel, wall, desktop, rack or VESA arm mounting

ƒ Supports 9U pre-drill Rackmount mounting hole

Touchscreen (Optional)

ƒ

Type

5-wire Resistive

ƒ

Interface

RS-232 and USB

ƒ

Lifespan

35 million touches at a single point

ƒ

Light Transmission

80% ±5

ƒ

OS Support

Windows XP,Vista,7,8,XPe,CE and Linu x

ƒ

Power Consumption

+5 V @ 100 mA

ƒ

Touch Resolution

Linearity

Environment

ƒ

Operation Temperature 0 ~ 50°C (32 ~ 122°F)

ƒ

Storage Temperature

-20 ~ 60°C (-4 ~ 140°F)

ƒ

Humidity (Storage)

10 ~ 90% non-condensing

ƒ

Waterproof

Front panel is IP65 compliant

ƒ

Vibration

5 ~ 500 Hz, 1 Grms (Operating, Random)

Introduction

FPM-3191G is a 19" color TFT LCD flat panel monitor specifically designed for industrial applications. With a viewing size as large as 19", it presents an simple display area as

well as vivid and sharp images for your HMI. It features direct VGA signal transmission. You can thus upgrade the displays without making changes to the e x isting system. The

onscreen display function also makes it easy to adjust the images on the screen. The whole chassis is designed in stainless steel and the front panel is made of aluminum with front

panel IP65 compliance.

All product specifications are subject to change without notice

Last updated : 5-May-2015
