M30620FCAFP датащи(PDF) 93 Page - Mitsubishi Electric Semiconductor |
|
|
|||||||||||||||||||||||||||||
M30620FCAFP датащи(HTML) 93 Page - Mitsubishi Electric Semiconductor |
|
|
93 / 274 page  Mitsubishi microcomputers M16C / 62A Group SINGLE-CHIP 16-BIT CMOS MICROCOMPUTER Timer B 93 Figure 1.14.21. Operation timing when measuring a pulse width Measurement pulse “H” Count source Count start flag Timer Bi interrupt request bit Timing at which counter reaches “000016” “1” “1” Transfer (measured value) Transfer (measured value) “L” “0” “0” Timer Bi overflow flag “1” “0” Note 1: Counter is initialized at completion of measurement. Note 2: Timer has overflowed. (Note 1) (Note 1) (Note 1) Transfer (measured value) (Note 1) Cleared to “0” when interrupt request is accepted, or cleared by software. (Note 2) Transfer (indeterminate value) Reload register counter transfer timing Figure 1.14.20. Operation timing when measuring a pulse period Count source Measurement pulse Count start flag Timer Bi interrupt request bit Timing at which counter reaches “000016” “H” “1” Transfer (indeterminate value) “L” “0” “0” Timer Bi overflow flag “1” “0” Note 1: Counter is initialized at completion of measurement. Note 2: Timer has overflowed. (Note 1) (Note 1) When measuring measurement pulse time interval from falling edge to falling edge (Note 2) Cleared to “0” when interrupt request is accepted, or cleared by software. Transfer (measured value) “1” Reload register counter transfer timing |
|
