µPD6124A, 6600A
14
Table 13-1. Control Register (P1) (2/2)
(b)
µPD6600A
Bit
D 9
Name
Test mode
–
Be sure to set 0.
0
1
Set
Value
Timer
D 8
D 7
D 6
D 5
D 4
D 3
D 2
D 1
D 0
HALT
D.P.
AD
MOD
K I/O
9
D.P.
AD8
RL A
A
CC
0 ←
STOP
NOP
f
/8
AD =0
8
OSC
IN
RUN
OSC
STOP
f
/12
AD =1
8
OSC
OUT
A 3
S-IN
Be sure to
set 0.
D0 .......................... Specifies data to be input to A0 when the accumulator is shifted to the left.
0: A3, 1:S-IN
D1 .......................... Specifies the status of KI/O, as follows:
0: input mode, 1: output mode
D2 .......................... Specifies the status of the timer, as follows:
0: Count stop, 1: Count execution
D3 .......................... Specifies the carrier frequency output from the REM pin.
0: fOSC/8, 1: fOSC/12
D4 .......................... Specify the MSB of the ROM data pointer.
D5 .......................... Be sure to reset them to 0.
D6 .......................... Determines what happen to the oscillation circuit when the HALT instruction is executed.
0: Oscillation does not stop
1: Oscillation stops (STOP mode)
D7 .......................... Be sure to set this bit to 0.
D8, D9 ................. These bits specify test modes. Be sure to set them to 0.
Remark
D0 = D8 = D9 = 0 on reset, and the other bits are undefined.
