Specifications

OUTPUT

Output Volt Amp Capacity (VA)

2200

Output kVA Capacity (kVA)

2.2

Output Watt Capacity (Watts)

1700

Output kW Capacity (kW)

1.7

Power Factor

0.8

Nominal Output Voltage(s)

Supported

120V

Frequency Compatibility

60 Hz

Output Voltage Regulation (Line

Mode)

-13% / +5%

Output Voltage Regulation (Battery

Mode)

+/- 5%

Output Receptacles

(6) 5-15R

Load Management Receptacles

Two switchable single outlet 5-15R load banks

Output AC Waveform (AC Mode)

Sine wave

Output AC Waveform (Battery Mode)

PWM sine wave

INPUT

Rated input current (Maximum Load)

15A

Nominal Input Voltage(s) Supported

120V AC

UPS Input Connection Type

5-15P

Input Circuit Breakers

20A

UPS Input Cord Length (ft.)

UPS Input Cord Length (m)

2.4

Recommended Electrical Service

20A 120V

Input Cord Length (ft.)

Input Cord Length (m)

2.4

Input Phase

Single-Phase

BATTERY

Full Load Runtime (min.)

11 min. (1700w)

Half Load Runtime (min.)

27 min. (850w)

Expandable Battery Runtime

Extended runtime supported via optional external battery packs
