1 / 1 page  Power Chip Shielded Inductors PCS2D14 15 DCR ( Ω) Rated Current Allied Part Number Inductance ( µh) Tolerance (%) Test Freq. PCS2D14-R47T-RC PCS2D14-1R5T-RC PCS2D14-1R8T-RC PCS2D14-2R2T-RC PCS2D14-2R7T-RC PCS2D14-3R9T-RC PCS2D14-5R6T-RC PCS2D14-6R8T-RC PCS2D14-8R2T-RC PCS2D14-100T-RC .47 1.5 1.8 2.2 2.7 3.9 5.6 6.8 8.2 10 30 30 30 30 30 30 30 30 30 30 100 100 100 100 100 100 100 100 100 100 0.040 0.063 0.075 0.094 0.106 0.138 0.188 0.213 0.281 0.294 2.00 1.80 1.65 1.50 1.35 1.10 0.95 0.85 0.80 0.70 ALLIED COMPONENTS INTERNATIONAL 714-665-1140 www.alliedcomponents.com RoHS PCS2D14-3R3T-RC 3.3 30 100 0.125 1.20 PCS2D14-4R7T-RC 4.7 30 100 0.169 1.00 (A) KHz,1v All specifications subject to change without notice. REVISED 12/11/08 Irms (A) 2.00 1.80 1.60 1.40 1.12 0.98 0.92 0.80 0.76 1.24 1.00 PCS2D14-120T-RC 12 30 100 0.394 0.62 Max 0.64 PCS2D14-4R1T-RC 4.1 30 100 0.169 1.00 1.00 Typ. Features • Shielded SMD Power Inductor • Low DC resistance • Ideal for DC-DC converter applications • Low profile Electrical Inductance Range: .47µh to 12µh Tolerance: 30% over entire range Operating Temp: -35ºC ~ +100ºC Rated Current: Current at which inductance drop is equal to 35% typ. Resistance to Soldering Heat Pre-Heat 150ºC, 1 Min. Solder Composition: Sn/Ag3.0/Cu0.5 Solder Temp: 260ºC +/- 5ºC for 10 sec. +/- 1 sec. Test Equipment (L): PM3260A / HP4284A / HP4285A (RDC): Chen Hwa 502BC Rated Current: HP4284A+HP42841A or Chen Hwa 1061 + Chen Hwa 301A Physical Packaging: 1000 pieces per 7 inch reel. Marking: 2 Character Alpha Code ∆ T=40ºC temp rise Irms: current at which Also, available in tighter tolerances Dimensions: Inches (mm) |
