DocID023994 Rev 3

19/34

M24C04-W M24C04-R M24C04-F

Maximum rating

33

7

Maximum rating

Stressing the device outside the ratings listed in Table 4 may cause permanent damage to

the device. These are stress ratings only, and operation of the device at these, or any other

conditions outside those indicated in the operating sections of this specification, is not

implied. Exposure to absolute maximum rating conditions for extended periods may affect

device reliability.

Table 4. Absolute maximum ratings

Symbol

Parameter

Min.

Max.

Unit

Ambient operating temperature

130

°C

Storage temperature

–65

150

°C

Lead temperature during soldering

1. Compliant with JEDEC Std J-STD-020D (for small body, Sn-Pb or Pb-free assembly), the ST ECOPACK®

7191395 specification, and the European directive on Restrictions of Hazardous Substances (RoHS)

2011/65/EU.

°C

PDIP-specific lead temperature during soldering

-

°C

DC output current (SDA = 0)

-

5

mA

Input or output range

–0.50

6.5

V

Supply voltage

–0.50

6.5

V

3. Positive and negative pulses applied on different combinations of pin connections, according to AEC-

Q100-002 (compliant with JEDEC Std JESD22-A114, C1=100 pF, R1=1500

Ω).

-

4. 4000 V for devices identified by process letters S or G.

V
