STPR805DF-STPR860DF

STPR805DF - STPR860DF

8.0A SUPER-FAST GLASS PASSIVATED RECTIFIER

Features

L

M

A

N

P

D

E

K

C

B

J

G

R

Pin 1

Pin 1

Pin 2

Pin 2

Case

·

Glass Passivated Die Construction

·

Diffused Junction

·

Super-Fast Switching Times for High Efficiency

·

High Current Capability and Low Forward

Voltage Drop

·

Surge Overload Rating to 125A Peak

·

Low Reverse Leakage Current

·

Plastic Material: UL Flammability

Classification Rating 94V-0

Mechanical Data

·

Case: Molded Plastic

·

Terminals: Plated Leads Solderable per

MIL-STD-202, Method 208

·

Polarity: See Diagram

·

Weight: 2.24 grams (approx.)

·

Mounting Position: Any

·

Marking: Type Number

Single phase, half wave, 60Hz, resistive or inductive load.

For capacitive load, derate current by 20%.

Characteristic

Symbol

STPR

805DF

STPR

810DF

STPR

815DF

STPR

820DF

STPR

830DF

STPR

840DF

STPR

850DF

STPR

860DF

Unit

Peak Repetitive Reverse Voltage

Working Peak Reverse Voltage

DC Blocking Voltage

50

100

150

200

300

400

500

600

V

RMS Reverse Voltage

35

70

105

140

210

280

350

420

V

Average Rectified Output Current

(Note 1)

°C

8.0

A

Non-Repetitive Peak Forward Surge Current

8.3ms single half sine-wave superimposed on

rated load (JEDEC Method)

125

A

Forward Voltage

0.95

1.3

1.5

V

Peak Reverse Current

°C

at Rated DC Blocking Voltage

°C

5.0

500

mA

Reverse Recovery Time (Note 2)

35

50

ns

Typical Junction Capacitance (Note 3)

85

60

pF

Typical Thermal Resistance Junction to Case

6.3

°C/W

Operating and Storage Temperature Range

-65 to +150

°C

Notes:

1. Case mounted on heatsink.

3. Measured at 1.0MHz and Applied Reverse Voltage of 4.0V DC.

TO-220AC

Dim

Min

Max

A

14.22

15.88

B

9.65

10.67

C

2.54

3.43

D

5.84

6.86

E

¾

6.35

G

12.70

14.73

J

0.51

1.14

K

3.53

Æ 4.09Æ

L

3.56

4.83

M

1.14

1.40

N

0.30

0.64

P

2.03

2.92

R

4.83

5.33

All Dimensions in mm
