ZLED7002

Toggle (Side-Step) Dual-Channel LED Driver

Data Sheet

August 10, 2011

© 2011 Zentrum Mikroelektronik Dresden AG — Rev.3.0

All rights reserved. The material contained herein may not be reproduced, adapted, merged, translated, stored, or used without

the prior written consent of the copyright owner. The information furnished in this publication is subject to changes without notice.

9 of 13













−

−

=

−

4

R

V

V

V

I

1

FD

LED

FSUB

CC

SUB

(3)

Where

2.5.

ZLED7002 Protection Features

2.5.1.

Over-Temperature Protection

The ZLED7002 includes protection from damage due to over-temperature conditions. The ZLED7002 automatically turns off if

its temperature is ≥160°C (typical). If the temperature returns to ≤140°C, the ZLED7002 turns on and continues normal

operation.

2.5.2.

Main LED Short-Circuit Protection

The ZLED7002 will detect a short-circuit on the MAIN LED. In this case, the ZLED7002 automatically turns off the MAIN LED

channel and activates the SUB LED channel.
