US5V330

Preliminary

CMOS IC

UNISONICTECHNOLOGIESCO.,LTD

5 of 6

www.unisonic.com.tw

QW-R502-908.a

POWER CHARACTERISTICS

PARAMETER

SYMBOL

TEST CONDITIONS (Note 1)

MIN

TYP

(Note 2)

MAX UNIT

Quiescent Power Supply

Current

0.1

3.0

µA

Supply Current per Input @

TTL HIGH

IN=3.4V (Note 3)

2.5

mA

Supply Current per Input per

MHz (Note 4)

EN

= GND Control Input Toggling 50%

Duty Cycle

0.25

mA

MHz

Notes:1. For Max. or Min. conditions, use appropriate value specified under Electrical Characteristics for the

applicable device.

4. This current applies to the control inputs only and represent the current required to switch internal

capacitance at the specified frequency. The S1, S2, and D I/O pins generate no significant AC or DC

currents as they transition. This parameter is not tested, but is guaranteed by design.
