CCVGA7C5

Preliminary

TVS

UNISONICTECHNOLOGIESCO.,LTD

5 of 6

www.unisonic.com.tw

QW-R223-021.a



ELECTRICAL CHARACTERISTICS (Note 1)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Diode Forward Voltage

IF=10mA

1.0

Logic High Output Voltage

VOH

IOH=-4mA, VCC=4.5V

4.0

Logic Low Output Voltage

VOL

IOL=4mA, VCC=4.5V

0.4

Input

Current

R, G and B Pins

IIN

VRGB=3.63V, VIN=VRGB or GND

±1

μA

HSYNC, VSYNC

Pins

VAUX=3.63V, VIN=VAUX

±1

μA

HSYNC, VSYNC

Pins

VAUX=3.63V, VIN=GND

-30.0

-72.5

-95.0

μA

VCC upply Current

ICC

VCC=5.5V, VAUX=VRGB=2.97V, All Inputs

and Outputs Floating

100

μA

VRGB supply Current

IRGB

R, G and B Pins at VCC r GND, All

Inputs and Outputs Floating

μA

Input

Capacitance

R, G and B pins

CIN

Note 2 Applies for All Cases

HSYNC,

VSYNC pins

DDC_DATA,

DDC_CLK pins

Pull−up Resistance

DDC_DATA, DDC_CLK pins

RPU

1.52

1.80

1.98

kΩ

ESD Withstand Voltage

VESD

VCC=5 V, VRGB=3.3V, VAUX=3.3 V

±8

SYNC Buffer L≥H Propagation

Delay

tPLH

CL=50pF, VCC=5.0V, RL=500Ω (Note 3)

7.0

15.0

SYNC Buffer H≥L Propagation

Delay

tPHL

CL=50pF, VCC=5.0V, RL=500Ω (Note 3)

7.0

15.0

SYNC Buffer Output Rise &

Fall Times

tR, tF

CL=50pF, VCC=5.0V, RL=500Ω (Note 3)

7.0

Notes: 1. All parameters specified over standard operating conditions unless otherwise noted.

2. Measured at 1MHz. R/G/B inputs biased at 1.65V with VRGB=3.3V. DDC_CLK and DDC_DATA biased at

2.5V with VCC=5V. HSYNC and VSYNC inputs biased at VAUX or GND with VAUX=3.3V and VCC=5V.

3. Applicable to the SYNC buffers only. Input signals swing between 0V and 3.0V, with rise and fall times ≤5

ns. Guaranteed by correlation to buffer output drive currents.
