TS331, TS332, TS334

Package pin connections

1

Package pin connections

Figure 1. Pin connections for each package (top view)

1. NC = not connected

2. The exposed pads of the DFN8 2x2 and the QFN16 3x3 can be connected to VCC- or left floating.

TS332

TS331

TS334

SOT23-5/SC70-5

SO8/MiniSO8

SO14/TSSOP14

TS331

DFN6 1.2x1.3

14

13

12

11

10

9

8

7

6

5

4

3

2

1

OUT2

VCC+

OUT1

IN1-

IN1+

IN2-

IN2+

OUT3

VCC-

OUT4

IN4+

IN4-

IN3+

IN3-

TS334

QFN16 3x3

TS332

DFN8 2x2
