8 / 42 page  www.ams.com Revision 1.0 8 - 42 AS3953 Datasheet - E le c t r i ca l C h a ra c t e r is t i c s 6.3 Electrical Specification VP_SPI = 3.0 V, Temperature 25ºC unless noted otherwise Symbol Parameter Min Typ Max Units Note ISB_SPI Standby consumption on VP_SPI 100 nA @ 25ºC VLIM Limiter voltage 5.2 5.8 V ILC = 30mA (DC) IS Supply current 250 µA Internal supply current measured in test mode on VREC, 13.56 MHz alternative pulses with amplitude 2Vpp, negative peak at VSS, forced to LC1 and LC2 VVP_REG Regulated supply voltage 1.65 1.8 2.01 V Set to 1.8V in EEPROM Configuration word VHF_PON HF_PON threshold (rising VREG) 2.3 V Guaranteed by design only VPOR_HY HF_PON hysteresis 0.8 V VMOD Modulator ON voltage drop 1.2 V ILC = 1mA 2.6 ILC = 30mA CR Resonance capacitor for die 25.2 28 30.8 pF Measured at 10MHz, 3.0Vpp (2.5Vpp) Guaranteed by design Resonance capacitor for MLPD package 38.2 31.3 34.4 Resonance capacitor for WL-CSP package 27 30 33 EEEN EEPROM endurance 100 000 cycles @ 125ºC EERET EEPROM retention 10 years |
|
